“RB” Block Wedge + HEMI 4340 Forged Superlight Crankshaft
$3,876.00
SCAT's Superlight Crankshafts are manufactured from non-twist, single plane 4340 forgings. These crankshafts have straight shot and chamfered oil holes; large radius on all journals; lightening holes in all rod journals; aero wing counterweights. "RB" Block Wedge + HEMI 4340 Forged Superlight Crankshaft is bridged for increased strength as well as precision ground, heat treated and nitrided for superior wear resistance.
| WARNING | This product may contain chemicals known to the State of California to cause cancer, and birth defects or other reproductive harm. |
|---|---|
| ADVERTENCIA | Este producto pueda que contenga químicos reconocidos por el estado de California que provocan cáncer, defectos de nacimiento u otros daños reproductivos. |
Additional information
| Weight | 70 lbs |
|---|---|
| Dimensions | 10 × 10 × 28 in |
| Style | Forged |
| Series | Superlight |
| Make | Chrysler |
| Engine | 426 |
| Type | Late Hemi |
| Material | Forged 4340 Steel |
| Rear Main Seal | 2-Piece |
| Balance | Internal |
| Lightened | Yes |
| Narrow Bearing | Yes |
| Rod Bearing Included | No |
| Main Bearing Included | No |
| Snout | Standard |
| Stroke | 3.750, 4.150, 4.250, 4.500 |
| Rod Length | 6.760, 6.800 |
| Rod Journal | 2.374, 2.200 |
